    Article summary

    Required permissions

    An employee must be assigned to the Shop with a Power User role or higher to create and edit templates on a Shop Owner level.

    You can use merge fields to insert data from ShopCtrl into the mail template to automatically retrieve it when you create an email based on the template.

    How to insert merge field

    To insert a merge field into the mail template:

    1. Open template for editing.
    2. Place cursor where you would like to insert the merge field and type the merge field name $$EntityName.FieldName$$. Or select and insert it using the pull-down merge field buttons in the menu above the mail body.
    3. Apply formatting depending on the merge field type.
    4. Proceed to edit the mail template as usual.

    You can always retrieve the whole list of merge fields by clicking the Available MergeFields button. Please see the List of Merge fields for more information.

    How to apply numeric merge field formatting

    To configure the output format of the numeric merge field in the mail template:

    1. Select the Numeric type merge field you would like to edit.
    2. Before the closing dollar signs, type: # and follow by the decimal format, for example: 0,00.
    3. Proceed to edit the mail template as normal.

    Examples of numeric fields formatting:

    Field CodeGenerated Output
    $$Order.OrderTotalExVat$$1,559,917.36
    $$Order.OrderTotalExVat#0.0000$$1559917.3600
    $$Order.OrderTotalExVat##,#.00$$1,559,917.36
    $$Order.OrderTotalExVat##,###.$$1,559,917
    $$Order.OrderTotalExVat#€#,###.00$$€1,559,917.36
    $$Order.OrderTotalExVat####,0.00kg$$1,559,917.36kg

    Please view .NET Custom numeric format strings for more information.

    How to apply date merge field formatting

    To configure the output format of the date merge field in the Word document template:

    1. Select the Date and Time Merge Field you would like to edit.
    2. Before the closing dollar signs, type # and the format you would like the date to be displayed. For example, yyyy-MM-dd.
    3. Continue editing template as normal.

    Examples of Date and Time fields formatting:

    Field CodeGenerated Output
    en-US    		Generated Output
    nl-NL    		Generated Output
    fr-FR
    $$Order.Date$$6/25/202125-6-202125/06/2021
    $$Order.Date#F$$Friday, June 25, 2021 3:06:22 PMvrijdag 25 juni 2021 15:06:22vendredi 25 juin 2021 15:06:22
    $$Order.Date#MMMM d$$June 25juni 25juin 25
    $$Order.Date#d-MM-yy$$25-06-2125-06-2125-06-21
    $$Order.Date#dd/MMM/yy$$25/Jun/2125-jun-2125/juin/21
    $$Order.Date#ddd, d MMMM yyyy$$Fri, 25 June 2021vr, 25 juni 2021ven., 25 juin 2021
    $$Order.Date#dddd dd, MMMM yyyy HH:mm$$Friday 25, June 2021 15:06vrijdag 25, juni 2021 15:06vendredi 25, juin 2021 15:06

    Please see .NET Date Time Formatting for more information.

    Email templates as merge fields

    Email templates themselves can be used as merge fields. For example, you can create a footer template or header template and use it throughout the other templates.

    The syntax of the mail template merge field is as follows: $$MailTemplate.{Template-code}$$.
    Where {Template-code} is the code of the existing mail template.

    To insert a merge field mail template click the Templates drop-down button in the menu above the body and select the field from the list. Or type it according to the format shown above.
